HT Jumpers & Wiring - Separate PTT Line Warning: Tigertronics has not verified the accuracy of all of the radio wiring information that is provided here. This information is provided for reference only and is NOT intended to replace our detailed. It is essential that you double-check this information against your radio's manual before doing the actual installation.
While it is fairly simple to install the SignaLink, it is possible to DAMAGE YOUR RADIO or the SignaLink by incorrectly installing it! Updated: November 13, 2017 IMPORTANT NOTES. SignaLink USB Users - The SignaLink USB is always powered by the computer's USB jack. When installing the jumpers for the SignaLink USB using the settings shown here and in our other documentation, please disregard the PWR jumper (do NOT install it!). All other jumper settings are the same. Note that if you mistakenly install the PWR jumper, it will make no difference in the operation of the unit as this pin is not internally connected. Select The Correct Diagram - When viewing the jumper settings below, BE CERTAIN THAT YOU ARE LOOKING AT THE CORRECT DIAGRAM for the radio connector that you will be using.
For any given radio, there are likely to be a different jumper settings for the Mic, Data and Accessory Port connectors. Jumper Wire Color - The jumper wires in the diagrams below are shown in color for illustrative purposes only. The color of the wires means nothing - they're just easier to see! The actual jumper wires that are included with the SignaLink are all the same color and can be used to jumper any signal.
RJ-45 Mic Connectors - There is a lack of standardization in the way that radio manufacturers number their RJ-45 Mic connectors. We have numbered our connector according to the dominant industry standard (as shown below), and all jumper settings shown in our documentation reflect this standard. Icom and Radio Shack follow this standard, but Kenwood, Yaesu and some others do not. All of the jumper settings show below have been corrected as necessary to account for any reversed pin numbering. If your radio is not shown below and you need to figure out your own jumper settings, then you will need to carefully determine how your mic connector is numbered to avoid reversing the connections!
SignaLink™, Industry Standard Kenwood, Yaesu, Some Others. PTT - You should verify in your radio manual that the radio PTT requirements do not exceed the specifications of the SignaLink keying circuit (please refer to the SignaLink manual) and that the PTT line is “Grounded” to make the radio transmit. If your radio exceeds the specifications listed or requires some other keying arrangement, then please contact our Technical Support Staff for suggestions. POWER - The SignaLink SL-1 and SL-1+ can usually be powered by the Accessory Voltage found on the Mic and Accessory Port connectors of most radios. If power is not shown in the jumper settings for your radio, then consult your radio manual to see if it is available. The SignaLink SL-1 and SL-1+ requires 6.75 to 15 VDC at 13ma (nominal). If this power is not available from your radio, then you will need to power the SignaLink SL-1 or SL-1+ externally (see the SignaLink manual for details).
Note that the SignaLink USB is always powered by the computer, so you can disregard the PWR jumper when installing this unit. RECEIVE AUDIO / SPEAKER AUDIO - Receive Audio is available on the Mic, Data, and Accessory Port connectors of most radios.
If Receive Audio is not shown in the jumper settings for your radio, then consult your radio manual to see if it is available. If it is not, then you will need to connect an audio cable between your radio's External Speaker or headphone jack, and the 'Speaker' jack on the back of the SignaLink. See the SignaLink Installation Manual for details. NOTE: Please read the 'Important Notes' above BEFORE you select your jumper settings. This will save time and may help prevent you from making a mistake that could possibly damage the SignaLink or your radio. Note that the SignaLink USB does NOT use the PWR jumper wire, so you can disregard this jumper during installation. All other jumper settings are the same.
8-Pin Round Mic Connector (use SLUSB8R, SL1+8R, or SLCAB8R) JP-1 Pin-out Pin 1 - Mic Input Pin 2 - PTT Pin 3 - N/C Pin 4 - N/C Pin 5 - N/C Pin 6 - Speaker. Pin 7 - N/C Pin 8 - GND Radio Models AR-146/147/446 Notes.Speaker audio and power are available on some models. Check your radio manual for availability of these signals and add the appropriate jumpers. The SignaLink USB is always powered by the computer and never needs external power. 8-Pin Round Mic Connector (use SLUSB8R, SL1+8R, or SLCAB8R) JP-1 Pin-out Pin 1 – Mic Input Pin 2 – PTT Pin 3 – N/C Pin 4 – N/C Pin 5 – N/C Pin 6 – N/C. Pin 7 – GND Pin 8 – GND Radio Models ALD-24T ALR-22T/22HT/72T DR-110T/112T DR- 130T/135E/135T DR-150/235T DR- 430T/435E/435T DR- 510T/570T DR-590T/592T/599T DR-600T /610E/610T DR-620E/620T DR-635 DR-1200 DX-70/70T /70TH/70EH DX-77 DX-SR8T/E DX-SR9 Notes.Speaker audio and power are available on some models. Check your radio manual for availability of these signals and add the appropriate jumpers.
The SignaLink USB is always powered by the computer and never needs external power. RJ-45 Mic Connector (use SLUSBRJ4, SL1+RJ45, or SLCABRJ4) JP-1 Pin-out Pin 1 – N/C Pin 2 – N/C Pin 3 – N/C Pin 4 – PTT Pin 5 – Mic GND Pin 6 – Mic Input Pin 7 – GND Pin 8 – N/C Radio Models DR-605E/605T DR-735T/E Notes Speaker audio and power are available on some models. Check your radio manual for availability of these signals and add the appropriate jumpers. The SignaLink USB is always powered by the computer and never needs external power. 6-pin Mini-DIN Data Port (use SLUSB6PM, SL1+6PM, or SLCAB6PM) JP-1 Pin-out Pin 1 – Data In Pin 2 – Ground Pin 3 – PTT Pin 4 – 9600 Out Pin 5 – 1200 Out Pin 6 – Squelch Radio Models DR-735T/E Notes 8-Pin Round Mic Connector (use SLUSB8R, SL1+8R, or SLCAB8R) JP-1 Pin-out Pin 1 – Mic Input Pin 2 – GND Pin 3 – N/C Pin 4 – N/C Pin 5 – N/C Pin 6 – N/C Pin 7 – PTT Pin 8 – N/C Radio Models PCS 5000/6000 PCS 7000 Notes Speaker audio and power are available on some models. Check your radio manual for availability of these signals and add the appropriate jumpers.
The SignaLink USB is always powered by the computer and never needs external power. 4-Pin Round Mic Connector (use SLUSB4R, SL1+4R, SL1-4R or SLCAB4R) JP-1 Pin-out Pin 1 – Mic Input Pin 2 – PTT Pin 3 – N/C Pin 4 – GND Radio Models TR-7/22/33 UV-3 Notes Power is not available on this connector, so you will need to use external power for the SignaLink Model SL-1+. The SignaLink USB is always powered by the computer and never needs external power. 8-Pin Round Mic Connector (use SLUSB8R, SL1+8R, SL1-8R or SLCAB8R) JP-1 Pin-out Pin 1 - Mic Pin 2 - PTT Pin 3 - NC Pin 4 - NC Pin 5 - NC Pin 6 - +5VDC Pin 7 - GND Pin 8 - GND Radio Models K2 K3 K3/S Notes The Mic jack on the K2 can be wired a number of different ways, so before installing the jumper wires, you MUST verify that the pin-out of your K2 matches that shown here. Sufficient power is not available on this connector, so you will need to use external power for the SignaLink Model SL-1+. The SignaLink USB is always powered by the computer and never needs external power.
Elecraft K3 rear panel Audio In, Audio Out and PTT connectors (use SLUSBK3, SL1+K3, or SLCABK3) JP-1 Pin-out Pin 1 - SPKR Pin 2 - GND Pin 3 - Mic Pin 4 - PTT Pin 5 - GND Pin 6 - GND Pin 7 - NC Pin 8 - NC Radio Models K3 K3/S Notes Some customers have found that the K3's 'Line In' gain (menu setting) is set to zero by default, thereby resulting in no power output when transmitting. If up experience this problem, then please consult your radio manual for instructions on turning up this control. Note that the K3 also has a menu setting for the 'Line Out' level, which can be turned up if needed to increase the RX Audio going into the SignaLink. Elecraft KX2 and KX3 Mic connector (use SLUSBKX3, SL1+KX3, or SLCABKX3) NOTE: The new Elecraft KX2 uses the same radio cable and jumper module as the Elecraft KX3. JP-1 Pin-out Pin 1 - Mic Pin 2 - PTT Pin 3 - GND Pin 4 - NC Pin 5 - NC Pin 6 - NC Pin 7 - NC Pin 8 - NC Radio Models KX2 KX3 Notes Two cable connections are required from the SignaLink to the Elecraft KX2/KX3 as follows:. Connect the RJ-45 end of the SLCABKX3 radio cable to the SignaLink’s “Radio” connector.
Connect the 4-pin right-angle TRRS plug to the KX2/KX3’s “Mic” jack, being sure to fully insert the plug. Connect the supplied right-angle mono audio cable between the SignaLink’s “SPKR” jack, and the KX2/KX3’s “Phones” jack.
Be sure that both plugs are fully inserted. KX2/KX3 Radio Settings: 1 - The “Mic Bias” setting in the KX2/KX3’s menu system should be turned OFF if you are using jumper wires. This setting can be left ON if you are using our SLMODKX3 jumper module as it has a built-in DC blocking capacitor. 2 - The “Mic Btn” setting should be set to either “PTT”, or “PTT Up.Dn.”. 3 - We recommend turning the KX2/KX3’s “Audio Effects” feature OFF, as it will likely cause receive problems during digital operation. 4-Pin Round Mic Connector (use SLUSB4R, SL1+4R, SL1-4R or SLCAB4R) JP-1 Pin-out Pin 1 – Mic Input Pin 2 – PTT Pin 3 – N/C Pin 4 – GND Radio Models IC-22/202/215 IC-245/280/402/502 IC-551 IC-701 Notes Power is not available on this connector, so you will need to use external power for the SignaLink Model SL-1+.
The SignaLink USB is always powered by the computer and never needs external power. 8-Pin Round MIC Connector (use SLUSB8R, SL1+8R, SL1-8R or SLCAB8R) IMPORTANT: This diagram is for the MIC JACK only. If the SignaLink is attached to your radio's 8-pin Accessory Port, then please see the diagram below under '8-pin DIN Accessory Port Connector'. JP-1 Pin-out Pin 1 – Mic Input Pin 2 – N/C. Pin 3 – N/C Pin 4 – N/C Pin 5 – PTT Pin 6 – GND Pin 7 – GND Pin 8 – Speaker. Radio Models IC-22U/25/27/28 IC-37A/38A/375 IC-45/47/48 IC-228/229/251AE IC-255/260/271/290 IC-471/475/490 IC-505/551/560/575 IC-707/718/720/725/726 IC-728/729/730/735 IC-736/737/738 IC-740/745 IC-746/746PRO IC-751 IC-756/756PRO IC-756PROII/PROIII IC-761/765/775/781 IC-820H/901 /910 IC-1201/1271/1275 IC-2400/2500 IC-3200/3210/3220/3230 IC-7400/7410 IC-7600/7700/7800 IC-9100 Notes.Speaker audio (usually Pin #8) and power (usually Pin #2) are available on some models. Check your radio manual for availability of these signals and add the appropriate jumpers.
The SignaLink USB is always powered by the computer and never needs external power. RJ-45 Mic Connector (use SLUSBRJ4, SL1+RJ45, SL1-RJ45 or SLCABRJ4) JP-1 Pin-out Pin 1 – +8V. Pin 2 – N/C Pin 3 – Speaker. Pin 4 – PTT Pin 5 – GND (mic) Pin 6 – Mic Input Pin 7 – GND Pin 8 – N/C Radio Models IC-F121 IC-207H./208H. IC-281A/281E/281H IC-703/706/706MKII IC-2000 IC-2100H./2200H. IC-2300H.
IC-2700./2720H. IC-2730A/E. IC-2800./2820. IC-7000. / IC-7100. IC-V8000.
ID-800H. ID-880. ID-4100A/E. ID-5100A/E.
Notes.Speaker audio and power are available on some models. Check your radio manual for availability of these signals and add the appropriate jumpers. The SignaLink USB is always powered by the computer and never needs external power.Speaker Audio is not available on the Mic jack of this radio, so do NOT install the SPKR jumper wire. Instead, use the supplied audio cable as detailed in the SignaLink USB manual. 6-pin Mini DIN Data Port Connector (use SLUSB6PM, SL1+6PMD or SLCAB6PM) JP-1 Pin-out Pin 1 – Data In Pin 2 – Ground Pin 3 – PTT Pin 4 – 9600 Out Pin 5 – 1200 Out Pin 6 – Squelch Radio Models IC-207H/208H IC-2720H IC-2800.
IC-2820 IC-703./706MKIIG. IC-746PRO. IC-7000.
IC-7100 IC-7400 IC-910H ## ID-880 IC-9100 Notes For special signals requiring un-filtered 'discriminator' audio, you will need to move the 'SPKR' jumper to pin #4 (9600 baud output). Note that some newer radios do NOT provide this output, so this may not apply to your radio.
Power is not available on any 6-pin mini DIN Data Port, so you will need to use external power for the SignaLink Model SL-1+. The SignaLink USB is always powered by the computer and never needs external power.IC-703 - If you are using the Data Port on this radio, then you must set menu #36 to '1200'.IC-706MKIIG - If you are using the Data Port on this radio, then you must set menu #29 to '1200'.IC-746PRO / IC-7000 - Some users have reported that this radio has a very sensitive Data Port, making power adjustments with the SignaLink USB's TX knob somewhat touchy.
If this is the case with your radio, then please click for a simple solution to this problem.Mic audio is NOT muted on this radio. ##You will need to connect the SignaLink to the 'Main' data port connection on this radio (not the 'Sub' port). 8-pin DIN Accessory Port Connector (use SLUSB8PD, SL1+8PD or SLCAB8PD) IMPORTANT: This diagram is for the ACCY PORT only. If the SignaLink is attached to your radio's 8-pin Round Mic Jack, then please see the diagram above under ' 8-Pin Round MIC Connector '. JP-1 Pin-out Pin 1 - RTTY or N/C Pin 2 - Ground Pin 3 - Send Pin 4 - Mod In Pin 5 - AF Out Pin 6 - Squelch Pin 7 - +13.8V Pin 8 - ALC Radio Models IC-275A IC-575A/H IC-707 IC-725/726 IC-728/729 IC-735/736/737/738 IC-7400 IC-746.
